110cc Dirt Bike Trail Bike Motorcycle 4 Stroke Adult Teen Large Size Wheel 17/14


SKU: 203749542406 Category:
110cc Dirt Bike Trail Bike Motorcycle 4 Stroke Adult Teen Large Size Wheel 17/14

Specification data engine type 110cc, 4 stroke, auto oil type petrol tank capacity 4l fuel unleaded driving mode chain starting system electric start tyre (front and rear) 17/14 inch seat hight 840mm throttle control twist control brake system front/rear disc brake front and rear suspension upside down fork &shocks max speed 65km/h + max load 100 kg brake front/rear hydrulic brake carton dimesion (mm) 1530x750x370 n.w. 70kg g.w. 75kg the product is 90% assembled.

All you need to do is assemble the handle bars and wheels. Really simple!

Please check all the bolts and nuts are tightened properly before riding.

Colour option: red or black !recommendations!
Due to transport reasons some minor adjustments may be needed.

E.g. Tightening off bolts or cables pre-ride checks check the following items each time before you ride.

The time required is minimal, and habitual performance of these checks will help ensure a safe, reliable ride.

If any irregularities are found during these checks, refer to the appropriate section and take the action required to return the motorcycle to a safe operating condition.

Any faults have to be reported to us within 7 days after the receipt of the bike.

!!! Warning !!!
Failure to perform these checks every day before you ride may result in serious damage or a severe accident engine spark plug: tighten to correct torque carburettor: adjusted properly idle speed: 1400 +/- 100 r/min (rpm) air cleaner: clean, properly installed.

Apply oil to air cleaner element muffler: not damaged frame tires: check overall condition; wear, cuts and other damage.

Check tire air pressure tighten the air valve cap securely spokes: check for any loose spokes. If necessary, torque.

Drive chain: check overall condition and chain slack with pushed out from the hollow of the chain guard is 0-5 mm. Lubricate the drive chain. If necessary.

Brakes: front and rear brakes function properly.

Brake lever play is 4-5 mm. If necessary, adjust.

Brake pedal travel is 15-25mm. If necessary, adjust.

Check brake lining wear.

Throttle: functions properly, returns smoothly.

Steering: action is sooth but not loose from lock to lock. No binding of control cables.

Fuel tank: mounted securely, no fuel leakage nuts, bolts, fasteners: tighten any loose bolts and nuts.

2. Break-in the first one hour that the motorcycle is ridden is designed as the break-in period.

If the motorcycle is not used carefully during this period, you may very well end up with a ‘broken down’ instead of a ‘broken in’ motorcycle.

Do not start moving or race the engine immediately after starting it, even if the engine is already warm. Run the engine for 15 to 20 minutes at idle speed to give the oil a chance to work up into all the engine parts.

Avoid the quick acceleration or starting and drive prudently for the first three hours of operation. Let the motorcycle cool completely.

The motorcycle ready for regular operation after this procedure is carried out.
